PLL Frequency Divider usintg the 555 (CB13732E)

Details
Written by: Newton C. Braga



We found this circuit in a 1977 Timers Cookbook. The circuit uses common components to divide a 1 kHz signal by 2. The output has an amplitude of 2 Vpp.




| Clique na imagem para ampliar |
