This power supply was originally designed to power the amplifier shown in CB16743E, but it can be used in other applications. The filter shock is the secondary winding of a 12 V x 3 A transformer.
| Clique na imagem para ampliar |
Symmetric 12 V to 18 V x 3 A Power Supply for Amplifiers (CB16744E)
