The integrated circuit of this project is not very common. The circuit is from 2003. This circuit is used in commercial telecommunications equipment at the time. Its is to compress the dynamic range of a microphone to obtain better performance from a communications transmitter. The input has a sensitivity of 50 mV.
| Clique na imagem para ampliar |
