We found this circuit in a 2006 publication. The circuit is simple, being powered by a 9 V battery, unlike some configurations that operate without power. The circuit has a single adjustment made in a trimpot.
| Clique na imagem para ampliar |
27MHz Stationary Wave Meter (CB18124E)
- Details
- Written by: Newton C. Braga
