Instrumentation Amplifier (CB20989E)

Details
Written by: Newton C. Braga



This ultra-low noise amplifier and simple power supply was found in Analog Devices documentation from the 90's. The circuit can be implemented with modern equivalent components.




| Clique na imagem para ampliar |
