Mosquito repellent (CB20813E)

Details
Written by: Newton C. Braga



We found this circuit generates signals from 200 Hz to 62 kHz and can be used to repel mosquitoes and mosquitoes. The circuit can be powered from 2 small batteries to 9 V battery.




| Clique na imagem para ampliar |
