This circuit was found in Radio Electronics magazine from June 1963. The range is small and the frequency is 37.355 MHz. The circuit is powered by a single 1.34 V battery.
Remote control tunnel transmitter (CB23885E)
- Details
- Written by: Newton C. Braga
