This circuit is similar to the previous one with 120 dB per octave. It was found in the July 1975 issue of Radio Electronics magazine. Any operational amplifier, such as the 741, can be used.
1 kHz High Pass Filter (CB24387E)
- Details
- Written by: Newton C. Braga
