Adjustable Bandpass Filter (CB24266E)

Details
Written by: Newton C. Braga



Using the 741 this circuit can be adjusted to values ​​between 1 Hz and 100 kHz. The power supply must be symmetrical. We found it in the Radio Electronics magazine of November 1973.




| Clique na imagem para ampliar |
