8-Channel Switch (CB24698E)
- Details
- Written by: Newton C. Braga
This circuit switches the capacitors of a digital filter with the 4046 IC (PLL). The circuit was found in the Radio Electronics magazine of May 1982. The circuit is CMOS.
