600 MHz Frequency Counter (CB24575E)

Details
Written by: Newton C. Braga



We found this circuit in the January 1979 issue of Radio Electronics magazine. Components are still common today, with the 7106 display driver standing out.




| Clique na imagem para ampliar |
