0.9 mW Amplifier (CB6288E)

Suggested by Amperex in 1968, this circuit is intended for hearing aids. The integrated circuit used, a TAA370 is not common today.

| Clique na imagem para ampliar |

Voltage Divider for Dual Supply (CB400)
This circuit split the voltage of a Power supply allowing it to be used as dual supply. The limit...
FSK Circuit with 4046 (CB25770E)
This modem circuit using a 4046 PLL was found in the October 1994 issue of Electronics Now. The...
Pre-amplifier Using the 741 (NI004E)
This simple circuit presents a voltage gain of about 1,500. The input impedance is high and the...
