12 V x 60 W inverter (CB7152E)

Details
Written by: Newton C. Braga



     The operating frequency of this circuit is 465 Hz and the input voltage is 12 VAC. The circuit is 65% efficient. We found it in a 1968 Motorola publication.




| Clique na imagem para ampliar |
