Customer Service Counter (CB6141E)

Details
Written by: Newton C. Braga



     This circuit can be used as an answering password system in a store, office, or other location. The circuit is from Intersil using components of the time. The circuit is from the 80's.








| Clique na imagem para ampliar |
