This circuit serves as a power stage for the CMOS alarms and oscillators given in the previous articles and in many applications in this section and the website. The power transistor can also be the TIP31 or TIP41 mounted on a heatsink. The circuit is from 90s documentation. The circuit is suitable for Shields.
