IR Illuminator for Night Vision Cameras (CB20973E)

Details: Written by: Newton C. Braga

This circuit was taken from a Popular Electronics from the 90's. The power step can be changed to operate with the most powerful LEDs available today.

| Clique na imagem para ampliar |
