This circuit is from the American magazine that no longer exists Science & Electronics, March-April 1981 issue. The circuit makes 7 LEDs blink sequentially in a back and forth rhythm, with speed that depends on R1 and C1. These components can be changed. The sound transducer is piezoelectric. Power must be supplied with a voltage of 5 V.
