Humidity sensor (CB25284E)

Details
Written by: Newton C. Braga



This circuit also detects IR, providing LED indication. The circuit is used to indicate humidity in bench tests. We found it in the Radio Electronics magazine of February 1990.




| Clique na imagem para ampliar |
