LM381 Low Distortion Amplifier (CB25274E)

Details
Written by: Newton C. Braga



This circuit was obtained from the February 1990 issue of Radio Electronics magazine. The circuit uses a single source, and the gain is given by the ratio R1/R2. The gain is 10 in this case.
