Varicap Beat Oscillator (CB25649E)
- Details
- Written by: Newton C. Braga
The varactor or varicap diode tunes the signal for listening to SSB signals on a common receiver. The circuit is from an Electronics Now from December 1993. T1 is a 455 kHz IF.
