This remote control was found in a 2006 documentation. The circuit activates a 12 V relay when receiving an infrared beam. The sensor is a phototransistor that must be installed in a tube with a converging lens for greater directivity and sensitivity. The sensitivity adjustment is made in P1. The transmitter is supplied with the project and powered by two batteries.
