With a touch of a sensor, it is possible to turn on or off incandescent lamps. The circuit must not be used with fluorescent or electronic lamps. The operation can be done both on the 110 V to 220 V network and the maximum power is 500 W. For power levels below 100 W, the triac does not need a heat sink. The sensor consists of a simple metal plate that must be touched with your fingers.
| Clique na imagem para ampliar |
